MRCOOL Universal 4-5 Ton High ESP Air Handler

 WARNING: This product can expose you to chemicals including refrigerants, which are known to the State of California to cause cancer [or birth defects or reproductive harm]. For more information, go to www.P65Warnings.ca.gov. ================================
13 people are viewing this product right now.   ================================

Original price was: $2,230.19.Current price is: $1,976.00.

You save: $254.19 (11%)
MRCOOLMRCOOL

Introducing the MRCOOL Universal 4-5 Ton High ESP Air Handler – the perfect solution for your air conditioning needs. With its high external static pressure, this air handler delivers exceptional performance and efficiency, providing you with the comfort and reliability you deserve. Don’t settle for less, choose the MRCOOL Universal 4-5 Ton High ESP Air Handler today and experience the difference!

______________________________________________ #1 in MRCOOL Universal DC Inverter Air Handlers
SKU: 4585 Category: Tags: , , , ,

Description

Universal Series DC Inverter High ESP Air Handler 4-5 Ton R410A 48,000-60,000 BTU 208-230V/1Ph/60Hz

The MRCOOL Universal 4-5 Ton High ESP Air Handler is a powerful solution designed specifically for high static pressure applications. It is the perfect choice for manufactured or mobile homes, or systems with ductwork restrictions that would otherwise put a strain on conventional air handlers not rated for high external static pressure.

This air handler boasts an efficient DC fan motor with blades specially designed for dynamic performance while remaining incredibly quiet. With a maximum static pressure of 250Pa, it can easily be installed in a variety of positions, including vertical, horizontal left, or horizontal right.

Furthermore, the MRCOOL Universal 4-5 Ton High ESP Air Handler is equipped with a robust metal filter that is both easy to clean and corrosion-resistant, ensuring a long-lasting service life. Get your hands on the MRCOOL Universal 4-5 Ton High ESP Air Handler today and enjoy unparalleled performance and reliability.

Features:

    • Up to 17 SEER
    • High Efficient Energy Saving DC Fan Motor
    • Internal Fan Blade Creates Low Noise
    • R-410A environmentally friendly refrigerant
    • AHRI Certified & ETL listed
    • High Efficient Energy Saving DC Fan Motor
    • Fire-Proof Electrical Box Design Offers Anti-Electric Shock Reserved Installation Space for the Circuit Breaker
    • Easy to Clean Metal Filter Protects Against Fire, Corrosion, and Deterioration
    • Multi-Position Installation: Upflow or Horizontal
    • 10-Year Registered Limited Warranty
    • 2-Step Condensation Protection

Additional Information

Weight 218 lbs

Leave a Reply

Your email address will not be published. Required fields are marked *

  • Rating

PROS

+
Add Pros

Cons

+
Add Cons
Choose Image

MRCOOL Universal Warranty

This non-transferable warranty provides for a total of 10 years of limited warranty coverage (Standard 5-year plus an additional 5-year extended parts
and compressor warranty). Unless otherwise noted in the terms outlined in the following warranty, you must register your product at one of the
following links to receive the additional 5 years of MRCOOL product warranty:

Read Document: mc-uni-wr-en-01

MRCOOL Universal Features

  • Much Quieter
    Ideal for Sound Restrictions
    For every 10 Decibels (dBa) a sound is twice as loud - making the Universal® at 55 dB(a) less than half as loud as a conventional condenser at 73 dB(a).
  • Slim Design
    Ideal for Zero Lot Lines
    Side discharge design takes less than half the area of conventional condensers. Perfect for city lots and between building applications where access is limited.
  • Versatile Installation
    Truly Universal Installation Options
    The Universal® has Flare, Flare-to-Weld or No-Vac® Quick Connect® line set options and Multi-Position Air Handler Installation (Upflow, Horizontal). Check out our patent.
  • All-Climate Performance
    NOT Your Typical Heat Pump
    Heating‡: 100% Capacity at -5°F and 78% Capacity at -22°F*
    Cooling‡: 100% Capacity at 115°F and 78% Capacity at 130°F*
    * outside temperature | ‡ based on 2 Ton model
  • Thermostat Compatibility
    Truly Universal Thermostat Options
    Compatible with any third-party thermostat including NEST® thermostats.
  • Reliable Comfort
    This DC Inverter Does It Better
    The Universal® DC Inverter moderates operating load, heating & cooling with less fluctuation for more comfortable climate control, extending component life for fewer breakdowns.
  • Side Discharge
    No Clogging / Less Space
    The Universal® takes half the area and, unlike conventional condensers, doesn't fill up with leaves, snow, and debris.
  • Versatile Application
    Install Almost Anywhere
    Replaces larger / louder condensers where sound/space limitations apply, and exceed conventional heat pump performance ranges for All-Climate applications with optimal coverage from 1000 sqft to 2500 sqft.
  • Energy Efficient
    Up to 20 Seer
    The Universal® DC Inverter moderates operating load, increasing efficiency for lower operating costs.
  • Gold Fin® Condenser
    Corrosion Resistant
    Live on the coast? Don’t worry, our condenser is built to resist long-term corrosion.
  • Warranty
    5-year Parts or 10-year Registered Parts
    The Universal comes with a 10-year warranty on all parts to the original registered end-user. See our Universal Warranty for details.
SEER 17
EER 10.5
HSPF 10
CFM 1600
TONNAGE 4_5 Ton
COOLING CAPACITY 54000 BTU
HEATING CAPACITY 54000 BTU
VOLTAGE 208/230 V
PHASE 1
CYCLE 60 Hz
MAX FUSE BREAKER 15 A
MIN CIRCUIT AMPACITY 8 A
REFRIGERANT TYPE R-410A
DECIBEL RATING 51 dBA
NUMBER OF SPEEDS 8 Speed
INVERTER DC
MIN AMBIENT COOL -5F – 129.2F
MIN AMBIENT HEAT -22 F – 75.2F
LINESET INCLUDED No
LIQUID LINE SIZE 3/8in
SUCTION LINE SIZE 3/4in
BLOWER MOTOR HP 1
FILTER TYPE Washable
FILTER SIZE 20-11/16 X 20-5/16 X 5/8
AUXILIARY HEATER AVAILABLE Yes
AUXILIARY HEATER SIZES 10KW / 15 KW / 20 KW
OVERLOAD PROTECTION Yes
ETL LISTED Yes
AHRI CERTIFIED Yes
REGISTERED WARRANTY 10-Year Limited Warranty
CONTAINS CHEMICALS Yes
PROPOSITION 65 WARNING Yes
NET DEPTH 24-3/4in
NET HEIGHT 57in
NET WIDTH 21-1/4in
NET WEIGHT 203 lbs
GROSS DEPTH 26in
GROSS HEIGHT 59-3/8n
GROSS WIDTH 27-1/4in
GROSS WEIGHT 218 lbs
